F-HLI-08_Facnor Drawing Internal Halyard Lock_001.PDF
Facnor Internal Halyard Lock 8T Technical Drawing
|
|
|
|
F-HLI-08_Facnor 2D Drawing Internal Halyard Lock_001.DWG
Facnor 2D Internal Halyard Lock 8T Technical Drawing
|
|
|
|
F-HLI_Facnor Dimensions Internal Halyard Lock_001.PDF
Facnor Dimensions Internal Halyard Lock Technical Drawing
|
|
|
|
F_Facnor Catalogue 2019-2020 EN_001.pdf
Facnor Products Catalogue 2019-2020
|
|
|
|
F-HLI_Facnor Internal Halyard Locks Range Dimensions EN_001.PDF
Facnor HLI Internal Halyard Locks Dimensions Diagram
|
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Ropes | |
|---|---|
| Recommended line - Max Ø (mm) | 10 |
| Boat |
|---|
| Load | |
|---|---|
| SWL (kg) | 8000 |
| NBL (kg) | 16000 |
| Dimensions | |
|---|---|
| Mast cutout height (mm) | 231 |
| Mast cutout width (mm) | 52 |
| Wall thickness (mm) | 24 |
| Material | |
|---|---|
| Material | Stainless Steel |
| Weight | |
|---|---|
| Weight (g) | 2656 |
