Mantagua NAVISLIM 2NM Port, Starboard and Stern Light Kit – Vertical Mount (Black or White Housing)
The Mantagua NAVISLIM 2NM Port, Starboard and Stern Light Kit includes one red 112.5° port sidelight, one green 112.5° starboard sidelight and one white 135° stern light, supplied together as a matched vertical mount set.
Designed for sailing yachts up to 20 metres in length, all three lights are fully compliant with COLREG 72 and provide the correct sector coverage required when underway under sail.
This kit effectively serves as the NAVISLIM range’s tricolour equivalent, offering full port, starboard and stern coverage using three discrete vertical-mount units rather than an integrated single tricolour fitting.
Certified 2 Nautical Mile Visibility
Each light in the kit delivers:
-
2 nautical mile visibility
-
Luminous intensity exceeding 5.4 candela
-
Precisely defined 112.5° (port & starboard) and 135° (stern) sectors
Together, they provide complete navigation lighting coverage for sailing vessels under 20m LOA when operating under sail.
A Practical Alternative to an Integrated Tricolour
Unlike some ranges, NAVISLIM does not include a single combined tricolour lantern. Instead, this three-light kit allows you to achieve full sidelights and stern light compliance using individual, low-profile LED units.
This approach offers:
-
Flexible mounting positions
-
Clean integration onto vertical surfaces
-
Simple replacement of individual lights if ever required
-
Consistent styling across the yacht
For many cruising yachts, particularly where masthead tricolours are not fitted or not preferred, this provides a straightforward and modern solution.
UV-Resistant PC + ASA Marine Housing
All three lights are manufactured from UV-stabilised PC + ASA, a high-performance marine engineering polymer blend developed for permanent exterior installation.
Polycarbonate (PC) provides impact resistance and structural strength, while ASA delivers excellent UV and weather resistance. This combination results in durable, colour-stable housings that resist:
-
UV degradation and fading
-
Saltwater exposure
-
Temperature cycling
-
Surface brittleness over time
Ideal for yachts exposed year-round, this ensures long-term durability in demanding marine environments.
IP67 Sealed and Energy Efficient
Each unit is fully sealed to IP67 standards, protecting the internal LED components from water ingress.
Operating on 10–30V DC, they are compatible with both 12V and 24V onboard systems. Power consumption is:
-
1.08W per sidelight
-
2.16W for the stern light
LED technology provides:
-
Immediate full brightness
-
Excellent vibration resistance
-
Long service life
-
No bulb replacement
Compact Vertical Installation
With dimensions of H38 x L85 x W45mm per unit, the vertical mount format integrates neatly onto cabin sides, coamings or transom surfaces while maintaining a discreet, low-profile appearance.
Each light is supplied with a 2m pre-wired cable and stainless M4 mounting screws for straightforward installation.
Part of the NAVISLIM Vertical Range
This three-light kit forms part of the wider Mantagua NAVISLIM vertical series, which also includes:
-
Individual port and starboard sidelights
-
Combined sidelight
-
2NM and 3NM masthead lights
-
Stern light
Together, they allow yacht owners to install a fully matched, certified navigation lighting system with consistent styling and dependable marine-grade construction.
The Mantagua NAVISLIM 2NM Port, Starboard and Stern Light Kit – Vertical Mount is a clean, modern alternative to a traditional tricolour lantern, delivering certified LED performance with flexible installation and durable UV-resistant housing.
